B2010−Exterior Walls

Category Archives: B2010−Exterior Walls

Metal Wall Panels on the Roof: How to achieve durability and reliability using sheet metal

All images courtesy Simpson Gumpertz & Heger

Some modern architectural designs use newer materials and metal panel assemblies for roofing applications, many of which are not intended to be used as roofing and, therefore, may not be well-suited for it. One such trend is the use of architectural metal wall panels as roofing to create a visually seamless transition between building walls and roof surfaces such as low-slope setbacks in the façade. This can impose unique challenges for the designer and contractor.

Read More


Richardsville Elementary – NET ZERO

net4

September 2010 marked the grand opening for Richardsville Elementary, the First Net-Zero Insulated Concrete Form School in the U.S. Warren County School district, the school board responsible for Richardsville, has been building energy efficient schools that are being recognized for their innovation across the United States.

Read More

Wind Load and Air Barrier Performance Levels

Photo courtesy DuPont Building Knowledge Center

This article describes the air barrier performance requirements for the desired wind load design specifications. The performance level is not determined by the type of air barrier material, but by the installation details. Examples of how these details can impact the performance level for a given air barrier system are provided, with special emphasis on mechanically fastened air barriers.

Read More

Durable Waterproofing for Concrete Masonry Walls: Redundancy Required

All images courtesy Building Diagnostics Inc.

A single-wythe concrete masonry wall may be a cost-effective structural element, but it can present challenges for waterproofing. The National Concrete Masonry Association (NCMA) recommends redundancy to keep concrete masonry walls dry through techniques at the surface of the wall, within the wall, and through adequate drainage systems. Unfortunately, many concrete masonry wall designs rely solely on admixtures in the concrete masonry units (CMUs) and mortar and surface-applied water repellents. However, low absorption values do not guarantee water penetration resistance; this disconnect in the industry is a leading reason for leakage in single-wythe concrete masonry walls.

Read More

Designing Masonry Buildings to the 2012 Energy Code: Thermal Mass Basics

A material’s thermal mass denotes its ability to store heat within a cycle of time. K-values, generally calculated on a 24-hour cycle, are important because they give general references to a material’s capabilities for storing heat. All materials may be considered for use in a thermal mass calculation, but steel, aluminum, and other metal claddings tend to cycle too quickly, while wood tends to cycle too slowly to offer desirable design values.

Read More
